Magnesium Alloy Motor
FM-03-017-26’’
- Magnesium Alloy Motor
- brushless geared motor
- Dc motor
- Hub motor
- Description: FM-03-017-26’’ Magnesium Alloy Motor dc brushless geared hub motor with waterproof cable for electric bicycle/E-bike
FM-03-017-26’’ Magnesium Alloy Motor dc brushless geared hub motor with waterproof cable for electric bicycle/E-bike
|
Model |
FM-03-017 |
|
Rated Voltage(V) |
24/36/48 |
|
Rated power(W) |
180-350 |
|
Wheel Size |
26” |
|
Rated Speed(km/h) |
25-30 |
|
Rated Efficiency(％) |
≥83 |
|
Reduction Ratio |
1:4.4 |
|
Weight (Kg) |
3.8 |
|
Open Size(mm) |
135 |
|
Drive and Freewheel |
6-9s |
|
Cable Location |
Shaft center right |
|
Hall Sensor |
Optional |
|
Integrate Speed sensor |
Optional |
|
Surface |
Shining/Black/Silver |
|
Brake Type |
V brake/Disc |
|
Salt fog test(h) |
24/96 |
|
Noise (db) |
<55db |
|
Waterproof Grade |
IP54 |
